PACKAGED
AIR COMPRESSOR SKID

TYPICAL
APPLICATION

The air compressor package skid is designed for various industrial applications, providing efficient and reliable compressed air solutions. Typical application areas include manufacturing plants, construction sites, oil and gas facilities, chemical processing industries, and automotive workshops. These skids are commonly used for powering pneumatic tools, controlling valves, operating machinery, and supporting production processes.

SKID
COMPONENT

• The air compressor package skid consists of several key components:

  1. Air Compressor Unit: The main component responsible for compressing air to the required pressure levels.

  2. Motor: Powers the air compressor, typically an electric or gas-powered motor.

  3. Receiver Tank: Stores compressed air and helps regulate pressure fluctuations.

  4. Control Panel: Provides operational controls and monitors system performance, including pressure and temperature readings.

  5. Filters: Removes contaminants such as dust, oil, and moisture from the compressed air.

  6. Dryer: Ensures the air is free from excess moisture, preventing corrosion or damage to equipment.

  7. Pressure Relief Valve: A safety device that releases excess pressure to prevent system overloading.

  8. Piping and Valves: Facilitates the flow of compressed air and allows for control of the system.

  9. Base Skid: Provides structural support and houses all components for easy transportation and installation.

  10. Cooling System: Maintains optimal operating temperatures for the compressor.

  Each component plays a vital role in ensuring efficient and reliable operation of the air compressor package skid.

optional
features

The air compressor package skid offers an optional feature of IoT (Internet of Things) integration. This advanced feature enables real-time monitoring and control of the compressor system remotely. With IoT, users can track critical parameters such as pressure, temperature, runtime, and maintenance schedules through a user-friendly dashboard on their devices. Alerts and notifications are sent for any irregularities, ensuring proactive maintenance and reducing downtime. This feature enhances operational efficiency, optimizes energy usage, and provides valuable insights for better decision-making.

Fabrication
Standards

The skid is engineered for ease of installation and maintenance, featuring modular designs and corrosion-resistant coatings. Detailed documentation, including material test reports (MTRs), quality control records, and inspection certificates, is provided to verify compliance with ASME and API standards.
